2.EL SAĞLAM DURUMDA.TEST EDİLMİŞTİR.
TEKNİK ÖZELLİKLER:
Model
Brand
EPoX
Model
EP-9NPA7I
Supported CPU
CPU Socket Type
939
CPU Type
Athlon 64 FX / Athlon 64 / Sempron
FSB
1000 MHz
Chipsets
Chipset
NVIDIA nForce4 4X
Memory
Number of Memory Slots
4×184pin
Memory Standard
DDR 400
Maximum Memory Supported
4GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express x16
1 x PCI Express x16
PCI Express x1
2 x PCI Express x1
PCI Slots
3 x PCI Slots
Storage Devices
PATA
2 x ATA100 4 Dev. Max
PATA RAID
NV RAID 0/1/0+1 JBOD
SATA 1.5 Gb/s
4 x SATA 1.5 Gb/s
SATA RAID
NV RAID 0/1/0+1 JBOD
Onboard Video
Onboard Video Chipset
None
Onboard Audio
Audio Chipset
Realtek ALC655
Audio Channels
6 Channels
Onboard LAN
LAN Chipset
Realtek 8201CL PHY
Max LAN Speed
10/100Mbps
Rear Panel Ports
PS/2
2
COM
1
LPT
1
USB 1.1/2.0
4 x USB 2.0
S/PDIF Out
1 x Coaxial
Audio Ports
3 Ports
Internal I/O Connectors
Onboard USB
6 x USB 2.0
Physical Spec
Form Factor
ATX
Dimensions (W x L)
12.0" x 8.9"
Power Pin
24 Pin
Packaging
Package Contents
EP-9NPA7I
User Manual
Driver Disk
Rear I/O Panel Shield
IDE/PATA Cable
FDD Cable
SATA Cable
Power Cable
Additional Information
Date First Available
January 25, 2006
